Teraflex JL: Tera30 HD Front Axle Housing – Bare (0–5” Lift) with HD Ball joints & Axle Shafts

JL Wrangler/Unlimited:

• Lift Height: 0–5”

• WMS-WMS: 66.5”

• Axle Tube: 3.25” x 0.5”

• Locker: NA

• Axle Shafts: 27-Spline

• Wheel Bolt Pattern: 5x5”

• Gear Ratio: NA

• Eliminates center axle disconnect

• Compatible with Dana 30 AdvanTEK (M186) internal components

• 3.25” O.D. x 0.5” wall extreme duty axle tube increases torsional strength to resist bending

• Asymmetric housing design for extra-long tube side strength

• Pre-installed inner axle seals

• HD forged inner knuckles w/ greater upper and lower section strength

• Ductile cast iron housing w/ increased rib gussets

• HD ductile iron differential cover w/ increased cover mounting area

• Smooth radius bottom design to glide over rocks and obstacles

• Integrated lower control arm skid plates

• High-flow oil passages and bottom oil drain hole for simple fluid changes

• UV protected triple-stage powder coat for corrosion resistance

• 1/4”-thick CNC laser cut axle brackets for extreme strength

• Integrated factory location upper control arm mount

• Pre-installed upper control arm bushings

• Proper pinion angle and raised track bar bracket for lifted applications

• Pre-drilled holes on spring perches for bump stop extension bolts

• Retains all factory ESP, ABS, and speedometer sensor capability

• 100% engineered, designed, and built in the USA w/ new components
